Index of /publicDatasets/CTU-Malware-Capture-Botnet-367-1

	Name	Last modified	Size	Description
	Parent Directory		-
	6f74f7c01503913553b0a6118b0ea198c5a419be86fca4aaae275663806f68f3.zip	2018-12-10 11:15	1.3M
	2018-10-9_win4.biargus	2018-12-10 11:15	4.0M
	2018-10-9_win4.binetflow	2018-12-10 11:15	1.2M
	2018-10-9_win4.capinfos	2018-12-10 11:15	1.2K
	2018-10-9_win4.dnstop	2018-12-10 11:14	4.2K
	2018-10-9_win4.mitm.weblog	2018-12-10 11:15	3.8K
	2018-10-9_win4.passivedns	2018-12-10 11:14	3.5K
	2018-10-9_win4.pcap	2018-10-10 01:12	10M
	2018-10-9_win4.rrd	2018-11-02 14:02	8.0M
	2018-10-9_win4.tcpdstat	2018-12-10 11:15	1.9K
	2018-10-9_win4.weblogng	2018-12-10 11:15	398K
	README.html	2018-12-10 11:16	4.0K
	README.md	2018-12-10 11:13	3.2K
	bro/	2018-12-10 11:16	-
	mitm.out	2018-10-10 01:12	57K
	ralabel-data.conf	2018-12-10 11:15	19K
	ralabel-datasets.conf	2018-12-10 11:15	6.0K
	suricata/	2019-03-23 14:41	-

Description

• Probable Name: Trojan/Miner/CoinMiner
• MD5: 301fae7f055e044b998dd0f4f92f34b5
• SHA1: 12a718b71bc81c7c965837f0bd2a487ae6d02693

• SHA256: 212a4695aa3830def3d79c0f18c9909ef2bf55cb5982fc7a53dc42c4

• Password of zip file: infected
• Duration:

• Proxy Usage: This capture did use an intermediate proxy.

• VirusTotal
• HybridAnalysis

• RobotHash

Files

• .capinfos
  • Capinfos file
• .dnstop
  • DNS top file
• mitm.out
  • Mitm proxy interception file of http and https
• .mitm.weblog
  • This is the HTTP and HTTPS web log that includes Labels. This is the preferred file for web analysis.
  • This file includes a header with the columns names. There are two new columns defined by us:
    • Column id: This number is unique for all the weblogs generated inside the same TCP connection. When a TCP connection is opened and several GET/POST, etc., requests are made inside it, all of them are assigned the same Id in this file.
    • Column timestamp_end: This is the timestamp when the weblog ended. If you use this with the id column you can compute the total duration of the TCP connection that generated all the weblogs. Similar to the duration of a hypothetical CONNECT request if this would have been done using a proxy.
• .passivedns
  • Passive DNS file
• .pcap
  • Original pcap file
• .rrd
  • RRD file for graphs
• .weblogng
  • WEB log of http traffic only. Generated with justsniffer
• .exe.zip
  • Original malware file
• bro
  • Folder with all the bro output files
• .biargus
  • Argus binary file. Bidirectional flows, 3600s of report time.
• .binetflow
  • Argus text file with bidirectional flows. Report time 3600 secs.
• .uniargus
  • Argus binary file. Unidirectional flows, 5s of report time.
• .uninetflow
  • Argus text file with unidirectional flows. Report time 5 secs. TAB as column separator.

IP Addresses

- Infected host: 192.168.1.114
- Default GW: 192.168.1.2

Timeline

Fri Oct 5 00:06:33 CEST 2018

started win4

Fri Oct 5 00:12:30 CEST 2018

infected

Last normal packet

1970/01/01 01:06:10.626268,0.000000,ipv6-icmp,fd77:48a1:c0bb::1,135, ->,fd77:48a1:c0bb:0:fc4d:dd70:65bf:b2d3,0,NNS,0,,1,86,86,s[32]=.........wH................X...r,,,s[32]=.........wH................X.

~ Tue, Oct 9 23:12:01 CEST 2018

power off

Remember that only 192.168.1.114 belongs to this capture. All other computers are sending multicast traffic from other machines.

Disclaimer

These files were generated in the Stratosphere Lab as part of the Malware Capture Facility Project in the CVUT University, Prague, Czech Republic. The goal is to store long-lived real botnet traffic and to generate labeled netflows files. Any question feel free to contact us: Sebastian Garcia: sebastian.garcia@agents.fel.cvut.cz

You are free to use these files as long as you reference this project and the authors as follows: Garcia, Sebastian. Malware Capture Facility Project. Retrieved from https://stratosphereips.org
